Authors
Muhammad Naseer Tomas Persson Isabela Righini Cecilia Stanghellini Henk Maessen Peter Ruoff Michel VerheulAbstract
CONTEXT For high latitude countries like Norway, one of the biggest challenges associated with greenhouse production is the limited availability of natural light and heat, particularly in winters. This can be addressed by changes in greenhouse design elements including energy saving equipment and supplemental lighting, which, however, also can have a huge impact on investments, economic performance, resources used and environmental consequences of the production. OBJECTIVE The study aimed at identifying a greenhouse design from a number of feasible designs that generated highest Net Financial Return (NFR) and lowest fossil fuel use for extended seasonal (20th January to 20th November) and year-round tomato production in Norway using different capacities of supplemental light sources as High Pressure Sodium (HPS) and Light Emitting Diodes (LED), heating from fossil fuel and electricity sources and thermal screens by implementing a recently developed model for greenhouse climate, tomato growth and economic performance. METHODS The model was first validated against indoor climate and tomato yield data from two commercial greenhouses and then applied to predict the NFR and fossil fuel use for four locations: Kise in eastern Norway, Mære in mid Norway, Orre in southwestern Norway and Tromsø in northern Norway. The CO2 emissions for natural gas used for heating the greenhouse and electricity used for lighting were calculated per year, unit fruit yield and per unit of cultivated area. A local sensitivity analysis (LSA) and a global sensitivity analysis (GSA) were performed by simultaneously varying the energy and tomato prices. RESULTS AND CONCLUSIONS Across designs and locations, the highest NFR for both production cycles was observed in Orre (116.9 NOK m−2 for extended season and 268.5 NOK m−2 for year-round production). Fossil fuel was reduced significantly when greenhouse design included a heat pump and when extended season production was replaced by a year-round production. SIGNIFICANCE The results show that the model is useful in designing greenhouses for improved economic performance and reduced CO2 emissions from fossil fuel use under different climate conditions in high latitude countries. The study aims at contributing to research on greenhouse vegetable production by studying the effects of various designs elements and artificial lighting and is useful for local tomato growers who either plan to build new greenhouses or adapt existing ones and in policy formulation regarding incentivizing certain greenhouse technologies with an environmental consideration or with a focus on increasing local tomato production.
Abstract
Tomato greenhouses at high latitudes (≥58°North) require supplemental light to enable high yields and year-round production. Supplemental light systems can differ in lamp type, high-pressure sodium (HPS) or light emitting diode (LED), and also vary in lamp capacity. Based on a combined greenhouse climate, tomato yield, and greenhouse economics model, a methodology was developed, for determining the optimal supplemental light system, dependent on local climate and economic conditions. Two optimisation objectives were considered separately, maximal energy use efficiency (EUE) and maximal net financial result (NFR). The developed methodology was applied to four different greenhouse locations in Norway. At each location, both optimisation objectives were reached with LEDs. The optimal lamp capacities range from 256 to 341 μmol m−2 s−1 (maximal EUE) and 302–323 μmol m−2 s−1 (maximal NFR). The economically optimal lamp capacity is little sensitive to climate conditions. At the lamp type respective NFR maxima, LEDs resulted, on average, in 10% higher tomato yield, 102.2 NOK m−2 year−1 higher NFR, and 35% higher EUE. Consequently, switching from HPS lamps to LEDs enables increasing productivity, energy efficiency and profitability of greenhouse tomato production. Furthermore, the difference between EUE and NFR optima was, on average, 24% lower in terms of EUE and 56% lower in terms of NFR, when using LEDs instead of HPS lamps. On farm-scale, the proposed methodology can be used as decision-support-tool for selecting an efficient and profitable supplemental light system for greenhouse tomato production, dependent on local climate and economic conditions.
Authors
Michel Verheul Henk Maessen Martina Paponov Anush Panosyan Dmitry Kechasov Muhammad Naseer Ivan PaponovAbstract
Studies of whole-plant responses of tomato to light environments are limited and cannot be extrapolated from observations of seedlings or short-term crops in growth chambers. Effects of artificial light sources like high pressure sodium (HPS) and light emitting diodes (LED) are mainly studied as supplement to sunlight in greenhouses. Since natural sunlight is almost neglectable in Norway during wintertime, we could study effects of different types of artificial light on crop growth and production in tomato. The goal of this experiment was to quantify the effects of artificial HPS top-light, installed at the top of the canopy, and LED inter-light, installed between plant rows, on fresh and dry matter production and fruit quality of greenhouse tomatoes under controlled and documented conditions. Our aim was to optimize yield under different light conditions, while avoiding an unfavourable source-sink balance. Tomato plants were grown under HPS top light with an installed capacity of 161, 242 and 272 W m−2 combined with LED inter-light with an installed capacity of 0, 60 or 120 W m−2. We used stem diameter as a trait to regulate air temperature in different light treatments in order to retain plant vigour. Results show that both HPS top light and LED inter-light increased tomato yield. However, the positive effect of supplemental LED inter-light decreased at higher amounts of HPS top light. Under the conditions in this experiment, with neglectable incoming solar radiation, an installed amount of 242 Watt m-2 HPS top light and a daily light integral (DLI) of 30 mol m-2 day-1 resulted in best light use efficiency (in gram fresh tomato per mol). Addition of LED inter-light to HPS top light reduced light use efficiency. Results show that winter production using artificial light in Norway is more energy efficient compared to production under sunlight in southern countries. Results can be used for modelling purposes.
Authors
Muhammad Naseer Tomas Persson Isabella Righini Cecilia Stanghellini Henk Maessen Michel VerheulAbstract
Greenhouses are complex systems whose size, shape, construction material, and equipment for climate control, lighting and heating can vary largely. The greenhouse design can, together with the outdoor weather conditions, have a large impact on the economic performance and the environmental consequences of the production. The aim of this study was to identify a greenhouse design out of several feasible designs that generated the highest net financial return (NFR) and lowest energy use for seasonal tomato production across Norway. A model-based greenhouse design method, which includes a module for greenhouse indoor climate, a crop growth module for yield prediction, and an economic module, was applied to predict the NFR and energy use. Observed indoor climate and tomato yield were predicted using the climate and growth modules in a commercial greenhouse in southwestern Norway (SW) with rail and grow heating pipes, glass cover, energy screens, and CO2-enrichment. Subsequently, the NFR and fossil fuel use of five combinations of these elements relevant to Norwegian conditions were determined for four locations: Kise in eastern Norway (E), Mære in midwestern Norway (MW), Orre in southwestern Norway (SW) and Tromsø in northern Norway (N). Across designs and locations, the highest NFR was 47.6 NOK m−2 for the greenhouse design with a night energy screen. The greenhouse design with day and night energy screens, fogging and mechanical cooling and heating having the lowest fossil energy used per m2 in all locations had an NFR of −94.8 NOK m−2. The model can be adapted for different climatic conditions using a variation in the design elements. The study is useful at the practical and policy level since it combines the economic module with the environmental impact to measure CO2 emissions.
Authors
Muhammad Naseer Tomas Persson Isabella Righini Cecilia Stanghellini Michel Verheul Henk MaessenAbstract
No abstract has been registered
Authors
Isabella Righini Bram Vanthoor Michel Verheul Muhammad Naseer Henk Maessen Tomas Persson Cecilia StanghelliniAbstract
A greenhouse climate-crop yield model was adapted to include additional climate modification techniques suitable for enabling sustainable greenhouse management at high latitudes. Additions to the model were supplementary lighting, secondary heating and heat harvesting technologies. The model: 1) included the impact of different light sources on greenhouse air temperature and tomato production 2) included a secondary heating system 3) calculated the amount of harvested heat whilst lighting was used. The crop yield model was not modified but it was validated for growing tomato in a semi-closed greenhouse equipped with HPS lamps (top-lights) and LED (inter-lights) in Norway. The combined climate-yield model was validated with data from a commercial greenhouse in Norway. The results showed that the model was able to predict the air temperature with sufficient accuracy during the validation periods with Relative Root Mean Square Error <10%. Tomato yield was accurately simulated in the cases under investigation, yielding a final production difference between 0.7% and 4.3%. Lack of suitable data prevented validation of the heat harvest sub-model, but a scenario is presented calculating the maximum harvestable heat in an illuminated greenhouse. Given the cumulative energy used for heating, the total amount of heating pipe energy which could be fulfilled with the heat harvestable from the greenhouse air was around 50%. Given the overall results, the greenhouse climate(-crop yield) model modified and presented in this study is considered accurate enough to support decisions about investments at farm level and/or evaluate beforehand the possible consequences of environmental policies.
Authors
Isabella Righini Bram Vanthoor Michel Verheul Muhammad Naseer Henk Maessen Tomas Persson I. Tsafaras Cecilia StanghelliniAbstract
No abstract has been registered
Abstract
No abstract has been registered
Authors
Luc Graamans Isabella Righini Bram Vanthoor Michel Verheul Muhammad Naseer Henk Maessen Tomas Persson I. Tsafaras Cecilia StanghelliniAbstract
No abstract has been registered
Abstract
No abstract has been registered
